MS-OMR (Multi-Spectral, Omni, Medium Range)
The Thermal-Beacon is an innovative and unique infrared emitter, radiates in the thermal spectrum (most efficiently at 3-5 micron) and does not emit radiation in the visible or the near infrared region. It is used as an identification device in the thermal spectrum region, for use with dismount soldiers, military vehicles, yachts, pilots, police SWAT teams, SAR, emergency services and mountain rescue teams.
The MS (Multi-Spectral) version allows the user to control the spectrum of radiation from the following:
- Only thermal region (for thermal cameras)
- Only near infrared region (for image intensifiers and SLS)
- Both thermal and near-infrared regions simultaneously.
Specifications:
| Parameter | Value |
|---|---|
| Detection range at 3-5μm using InSb Detector & 250mm lens: | 3km |
| Detection range at 3-5μm using Airborne Optics (Litening): | 15km |
| Detection range at NIR using any IR light intensifier: | 10km |
| Radiation divergence: | Half-sphere |
| Operational Voltage | 4 x CR123 batteries |
| Operational time: | 2 hours |
| Repetition Rate : | 1Hz |
| Dimensions- Beacon: | (H)20 x (L)--- x (W) Ø 54mm |
| Dimensions- Control box | (H)140 x (L)--- x (W) Ø 25mm |
| Weight (without batteries): | Beacon: 182gr Control Unit: 145gr |
