| Parameter | Value |
|---|---|
| Detection Range: | |
| At 3-5μm using InSb Detector & 250mm lens | 5km |
| At 3-5μm using Airborne Optics (Litening) | >15km |
| At 8-12μm using a microbolometer camera at narrow field | >1km |
| Operation Voltage | 18-75 VDC |
| Radiation divergence | 120° Horizontal and vertical |
| Repetition Rate | 2Hz |
| Dimensions | 70 x 52 x 55mm |
| Weight | 300gr |
| Operating Temperature | -20Cᵒ up to +55Cᵒ |
| Storage Temperature | -40Cᵒ up to +71Cᵒ |
